Ordering Information |
|
P/N |
Description |
|
UTX-3115B-S6A2E |
Barebone |
|
UTX-3115SA4-S6A2E |
System w/4antenna, 2G RAM & 32G SSD |
|
UTX-3115SA4P-S6A2E |
System w/4antenna, 2G RAM, 32G SSD, IDP |
|
UTX-3115SA4L-S6A2E |
System w/4antenna, 2G RAM & 32G SSD |
|
UTX-3115FS-S6A2E |
Emb.sys.UTX-3115.2G RAM.SSD.AC7260 module. HE910G module.4Antenna. |
|
UTX3115SA4P1-S6A2E |
System w/4antenna, 2G RAM& 32G SSD, IDP3.1 |
|
UTX-3115FSP1-S6A2E |
System w/4antenna, 2G RAM& 32G SSD,AC7260 WIFI module,HE910G 3G module.4antenna.IDP3.1 |
|
Note: *Two antenna post for Wifi module & two post for 3G/LTE |
|
Packing List |
|
|
Part Number |
Description |
|
UTX-3115 |
1 x UTX-3115 unit |
|
96PSA-A36W12W7 |
36W 12V 3A AC/DC Power Adaptor |
|
1930000198 |
2x Screw M2x4L for miniPCIE module use |
|
Optional Items |
|
|
Part Number |
Description |
|
1700001524 |
Power Cable 3-pin 180cm, USA type (For power adapter 96PSA-A36W12W7) |
|
170203183C |
Power Cable 3-pin 180cm, Europe type (For power adapter 96PSA-A36W12W7) |
|
170203180A |
Power Cable 3-pin 180cm, UK type (For power adapter 96PSA-A36W12W7) |
|
1700008921 |
Power Cable 3-pin PSE Mark 183cm (For power adapter 96PSA-A36W12W7) |
|
1702002600-01 |
Power cable 3-pin 183 cm, USA type (For power adapter 1757004522-01) |
|
1700018705 |
Power cable 3-pin 183 cm, Europe type (For power adapter 1757004522-01) |
|
1700018704 |
Power cable 3-pin 183 cm, UK type (For power adapter 1757004522-01) |
|
1700000237-01 |
Power cable 3-pin 183 cm, PSE type (For power adapter 1757004522-01) |
|
AIMB-0BRK-VM01E |
UTX-3115 Vesa Mount bracket kit |
|
AIMB-0BRK-WM01E |
UTX-3115 Wa丨丨mount bracket kit |
|
AIMB-0BRK-DR01E |
UTX-3115 DIN rail bracket kit |
|
EWM-C118HD01E |
2-band Cellular Module, SIM holder, half-size |
|
EWM-W158F01E |
Advantech 802.11abgn 2T2R, Wide-Temp Module |
